Product Description
Primary differences lie in capacity, overall dimensions, weight, main motor power, tilting motor/hydraulic cylinder power, unloading method, and blade form (Double S-type, Single Paddle, Double Z-type). All models maintain consistency in material standards and core component brands: side plates are chrome-plated Q235 carbon steel; dough-contact parts (tank, shaft, paddles) are stainless steel; outer cover is SUS304 stainless steel; bearings are Japanese NSK; motor and reducer are German SEW/Siemens; and control electrical components are primarily French Schneider.
Item | HMS250 | HMZ400 | HMZ550 | HMZ600 |
Mixing Capacity | 250 kg/batch | 400 kg/batch (Tank: 750L) | 550 kg/batch | 600 kg/batch (Tank: 1065L) |
Working Speed | 20-40 rpm (Frequency Conversion) | 20-40 rpm (Frequency Conversion) | 20-40 rpm (Frequency Conversion) | 20-40 rpm (Frequency Conversion) |
(L*W*H) | 2090*850*2200 mm | 1900*1050*2100 mm | 2090*1050*2200 mm | 2300*1100*2250 mm |
Theoretical Weight | ~2.5 T | ~3.5 T | ~3.5 T | ~5 T |
Main Motor Power | 18 kW | 30 kW | 37 kW | 45 kW |
Tilting Motor (Cylinder) | 0.75 kW | 3.75 kW | 3.75 kW | 3.75 kW |
Blade Form | Horizontal Double S-type | Horizontal Single Paddle | Horizontal Double Z-type | Horizontal Single Paddle |
Unloading Method | Motor-driven, Single Side | Hydraulic, Single Side | Hydraulic, Single Side | Hydraulic, Single Side |
(Uniform Material & Brand Standards)
Side Plate: Q235 carbon steel, chrome-plated.
Dough-contact Parts (Tank, Shaft, Paddles): Stainless steel.
Outer Cover: SUS304 stainless steel (Cover door: Painted Q235).
Bearings: Japanese NSK.
Motor & Reducer: German SEW/Siemens.
Control Electrical: Primarily French Schneider.
(Core Features)
Produces dough with smooth surface, good texture, elasticity, toughness, and extensibility.
PLC control with touch screen operation.
Hygienic design without dead angles.
Equipped with emergency stop and safety alarms.
Jacketed tank for temperature control (digital display).
